ARC RATED GORE-TEX PYRAD® GARMENTS for Electric Utilities

Category 3 arc protection garments that are up 20% lighter in dry or wet conditions than other comparable garments. Keeps wearers dry and comfortable outdoors, even in extended periods of heavy rain.

KEY BENEFITS

Explore the high-level protective benefits of this technology application.

Arc Rated

Lightweight

Breathable

Durably waterproof

PYRAD® fabric technology by GORE-TEX LABS blocks convective heat flow during arc exposure and stops flame propagation by forming a carbonaceous char with the textile.

When wet or dry, these garments are up to 20% lighter than other garments with category 3 arc protection, allowing the wearers to work outside for extended periods during heavy rain.

As breathability is key for an improved comfort and leads to an increased wearer acceptance, GORE-TEX PYRAD® fabrics are highly breathable and avoid build up of moisture from inside.

Arc rated GORE-TEX PYRAD® garments are durably waterproof and keep the wearer dry and comfortable when working long hours outdoors in heavy rain.

DURABLE RAIN PROTECTION FOR OUTDOOR ELECTRICAL WORKERS

Arc rated GORE-TEX PYRAD® garments are durably waterproof and reliably protect electrical workers against the thermal hazards of an electric arc. They stay lightweight and comfortable even when wet.

This technology is available in two different laminates, both of which are Cat 3 arc rated (30 cal / cm2):

$Electrical utility worker performing a routine maintenance task.$ $Electrical utility worker performing a routine maintenance task.$

A 2-layer laminate that protects against seasonal rain occurrences and is adapted for moderate working conditions. The garment is very lightweight and very breathable.

$Electrical utility worker performing a highly demanding task.$ $Electrical utility worker performing a highly demanding task.$

A 3-layer laminate that protects against harsh and wet weather. While being lighter than competitive products, this is a robust and rugged garment ideal for highly demanding work tasks.

How It Works

Upon arc exposure, the arc rated GORE-TEX PYRAD® fabric reduces convective heat flow and stops flames or damage from an arc flash by forming a carbonaceous char with the fabric. Heat transfer is reduced, the physical integrity of the fabric is maintained effectively for reduced heat transfer to the skin.

Standards

3-layer laminate:
ASTM F1891-19 | NFPA 70E-2018: ARC & FLAME RESISTANT RAINWEAR
ASTM F2733: FLAME RESISTANT RAINWEAR FOR PROTECTION AGAINST FLAME HAZARD
Contact garment manufactuers for jacket and bib styles that are compliant to this standard
ANSI/ISEA 107 / CSA Z96: HIGH VISIBILITY
ASTM F1868 | ASTM F1868: EVAPORATIVE RESISTANT (Ret) – BREATHABILITY

2-layer laminate:
ASTM F1891 - NFPA 70E (USA) & CSA Z462 (CAN): ARC AND FLAME RESISTANT RAINWEAR
ASTM F1959: ARC RATING OF MATERIALS FOR CLOTHING – CAT 3 (ATPV ≥ 30 cal/cm²)
ASTM F2733: FLAME RESITANT RAINWEAR FOR PROTECTION AGAINST FLAME HAZARD
Contact garment manufacturers for jacket and bib styles that are compliant to this standard.
ANSI/ISEA 107 / CSA Z96: HIGH VISBILITY- YELLOW & ORANGE
ASTM F1868 / ISO 11092: EVAPORATIVE RESISTANT (Ret) – BREATHABILITY

OTHER FEATURES:
OEKO-TEX® STANDARD 100: Supplement for “PPE and PPE material”- Annex 4 product class II Certified.
CALIFORNIA PROP 65 Compliant
